MONO or POLY

Mono        Mono         Mono

Maximum power (Wp)

160wp       155wp        150Wp

Maximum power voltage (V)

36              36                36

Maximum power current (A)

4.45           4.3                4.2

Open circuit voltage (V)

43.2           43.2               43.2

Short circuit current (A)

4.8             4.72              4.64

Number of cells (Pcs)

               72

Size of module (mm)

1580*808*40mm( 125*125mm cell)

Brand Name of Solar Cells

CEEG

Maximum system voltage (V)

960

Temperature coefficients of Isc (%)

0.065+/-0.015%/

Temperature coefficients of Voc (%)

-2.23+/-0.1mv/

Temperature coefficients of Pm (%)

-0.5+/-0.05%/

Temperature coefficients of Im (%)

+0.1/

Temperature coefficients of Vm (%)

-0.38/

Temperature Range

-40+80

Tolerance Wattage (e.g. +/-5%)

+/-5%

Surface Maximum Load Capacity

60m/s(200kg/sq.m)

Allowable Hail Load

steel ball fall down from 1m height

Weight per piece (kg)

15

Junction Box Type

GY-BOX-5C( TUV )

Length of Cables (mm)

900mm

Cell Efficiency (%)

16.25%

Module Efficiency (%)

14.4%

Output tolerance (%)

+/-5%

Frame (Material, Corners, etc.)

Aluminum

Standard Test Conditions

AM1.5  100mW/cm2  25C

Warranty

2 years product warranty and 25 years 80% of power

FF (%)

73%

Packing

2PCS/CTN,532PCS/228CTN/40/20FCL
