The machine applies both sides feeding and simultaneously shaping workmode,one side forming:"",and one side forming is for installing hooks"".Apply shared-plate flange, therefore, the rectangle duckwork flange can be fast processed. It features low making cost and high installing efficiency, convenient for standard and batches of production. The product is widely applied in the occasions which present low requirements in rectangle duckwork section. . Free of riveting , fast and convenient installation , fine sealing performance , high quality and substantial price
Main parameters:
Model
Motor
(KW)
Thickness
(mm)
Weight
(kg)
Size(L.W.H)
(mm)
LTA-10A
2.2
0.6-1.0
984
3520×750×830
LTA-12
3.0
0.8-1.2
1060
3550×780×890
Note:mould usd in installation need equip separately.
