Main Specifications
| Engine | |
| Model | D6114ZG |
| Power rate | 132KW |
| Rated speed | 2000rpm |
| Type | Vertical water cooling four stroke direct injection |
| Rated fuel consumption | 215 g/kw·h |
| Traveling performance | |
| Grade ability | 35% |
| Traveling speed (km/h) | |
| Forward I | 2 |
| Forward II | 4 |
| Forward III | 10.5 |
| Axle | |
| Drive type | Rear wheel drive |
| Front axle load | 13200 kg |
| Rear axle load | 8800 kg |
| Steering system | |
| Type | Articulated frame hydraulic steering |
| Steering cylinder | Two cylinders |
| Steering pump | Gear pump |
| Working pressure | 13MPa |
| Steering angle | ±36º |
| Min. steering radius | 7500mm(outer side) |
| 5400mm(inner side) | |
| Dimensions | |
| Overall length | 5820 mm |
| Overall width | 2298 mm |
| Overall height | 3050 mm |
| Drum width | 2130 mm |
| Wheel base | 3160 mm |
| Drum Dia | 1570 mm |
| Tyre specification | 23.1-26 |
| Min. ground clearance | 432 mm |
| Brake system | |
| Parking brake | Hand operated drum brake |
| Service brake | Disc brake actuate rear wheels |
| Working equipment | |
| Type | Hydraulic vibration |
| Frequency 30 Hz | |
| Amplitude | 2.0/1.0 mm |
| Static linear load | 460 N/cm |
| Dynamic linear load | 631 N/cm |
| Vertical oscillation | 8º |
| Drum shell thickness | 30 mm |
| Centrifugal force(high ampl.) | 360 KN |
| Centrifugal force(low ampl.) | 280 KN |
| Refill capacity | |
| Hydraulic tank | 150L |
| Gear box | 25L |
| Drive axle | 25L |
| Brake booster | 10L |
| Fuel tank | 180L |
| Engine crank case | 19L |
