Engine | |
Model | Cummins L340 30 |
Type | Water cooled, turbocharged |
Rated power | 253kw |
Rated speed | 2200rpm |
Main Technical Specification | |
N.V.W | 9850kg |
Permitted towing mass | 56500kg |
Max. Traveling speed | 98km/h |
The fifth wheel | 90# |
Approach angle | 18° |
Departure angle | 32° |
Front overhang | 1500 |
Rear overhang | 810 |
Dimensions | |
Overall size | 7060×2500×3600mm |
Wheel base | 3400 1350mm |
Tread | 2027/1820/1820mm |
Transmission System | |
RT11509C synchromesh.9 forward & 1 reverse | |
Ratio | |
---Forward | 12.42,8.26,6.08,4.53,3.36,2.47,1.81,1.35,1.00 |
---Reverse | 12.99 |
Axle and Type | |
Front axle | 5 ton |
Rear axle | 13/13 ton |
Ratio | 4.11 |
11.00R20 | |
Clutch and Brakes | |
Single-plate dry coil-spring clutch, hydraulically operated with air assistance | |
Service brake | Dual circuit compressed air brake |
Parking brake | Spring energy operating on rear wheels |
Auxiliary brake | Engine exhaust brake |
Electric System | |
Negative grounded | |
System voltage | 24V |
Batteries | 24V/165Ah |
Cab | |
Flat head, high roof with sleeper type, new inside decoration |
