| Engine | |
| Model | Cummins L315 30 |
| Type | Water cooled, turbocharged |
| Rated power | 231kw |
| Rated speed | 2200rpm |
| Main Technical Specification | |
| N.V.W | 8200kg |
| Permitted towing mass | 45000kg |
| Max. traveling speed | 90km/h |
| The fifth wheel | 90# |
| Approach angle | 18° |
| Departure angle | 32° |
| Front overhang | 1460 |
| Rear overhang | 1080 |
| Dimensions | |
| Overall size | 6940×2500×3600mm |
| Wheel base | 1700 2700mm |
| Tread | 1960/1960/1860mm |
| Transmission System | |
| 9JS119TB,9 forward & 1 reverse | |
| Ratio | |
| ---Forward | 11.02,6.55,4.64,3.36,2.71,1.95,1.38,1.00,0.81 |
| ---Reverse | 11.52 |
| Axle and Type | |
| Front axle | 5/5 ton |
| Rear axle | 13 ton |
| Ratio | 4.44 |
| 11.00-20 | |
| Clutch and Brakes | |
| Single—plate dry coil-spring clutch, hydraulically operated with air assistance | |
| Service brake | Dual circuit compressed air brake |
| Parking brake | Spring energy operating on rear wheels |
| Auxiliary brake | Engine exhaust brake |
| Electric System | |
| Negative grounded | |
| System voltage | 24V |
| Batteries | 24V/165Ah |
| Cab | |
| Flat head, high roof with sleeper type, new inside decoration | |
