Engine | |
Model | Cummins ISDe270 30 |
Type | Electronic control common-rail, turbocharged |
Rated power | 198kw |
Rated speed | 2200rpm |
Main Technical Specification | |
N.V.W | 7500kg |
Permitted towing mass | 35200kg |
Max. Traveling speed | 98km/h |
The fifth wheel | 50# |
Approach angle | 20° |
Departure angle | 40° |
Front overhang | 1470 |
Rear overhang | 1020 |
Dimensions | |
Overall size | 5990×2490×3600mm |
Wheel base | 3500mm |
Tread | 1986/1860mm |
Transmission System | |
DF8S1200C,8 forward & 1 reverse | |
Ratio | |
---Forward | 12.745,8.143,5.702,3.913,3.257,2.081,1.475,1.00 |
---Reverse | 10.812 |
Axle and Type | |
Front axle | 5 ton |
Rear axle | 13 ton |
Ratio | 4.875 |
11.00R20 | |
Clutch and Brakes | |
Single—plate dry coil-spring clutch, hydraulically operated with air assistance | |
Service brake | Dual circuit compressed air brake |
Parking brake | Spring energy operating on rear wheels |
Auxiliary brake | Engine exhaust brake |
Electric System | |
Negative grounded | |
System voltage | 24V |
Batteries | 24V/165Ah |
Cab | |
Flat head, high roof with sleeper type, new inside decoration |
