Operation Principle
The transmission system of the equipment adopts hydraulic style.And the hydraulic pump makes use of the high pressured oil to force the hydraulic cylinder and promote the pallet up and down,which completess car in and out.when the pallet asceds to the position,car can be allowed to park at the ground sapce.
Character
Easy operation Safe performance Convenient parking Low noise
Less occupied ground Beautiful&fashionable appearance
Easy and quick installation
Used for family and office building
Easy operation Safe performance Convenient parking Low noise
Less occupied ground Beautiful&fashionable appearance
Easy and quick installation
Actuating Device:
1. Motor + Chain + Car loading Pallet
2. Motor + Steel rope + Car loading Pallet
3. Hydraulic pump + Cylinder + Steel rope + Car loading Pallet
Parking |
Type |
LEPP706 |
Parked Vehicles |
2 |
|
Single Vehicle Weight (kg) |
≤2000 |
|
Dimensions (mm) |
a |
3373 |
b |
1955 |
|
c |
1150 |
|
d |
3814 |
|
e |
2490 |
|
f |
2000 |
|
g |
2679 |
|
Drive Mode |
Hydraulic |
|
Power |
3 Phase 380V 50Hz |
