Shenzhen BBT Electronics Co., Ltd
Configuration
CPU:Intel ATOM Processor dual Core N570(1.66GHz)
Chipset:Intel NM10 Express chipset
Ram:Standard 1GB 1066MHz DDR3 SDRAM,could enlarge to 2GB
Display screen:10.1" 1024*600 LCD
Video ports:VGA output
Audio ports:3.5mm/40mw earphone
Audio Speakers:Stereo speaker
Input Devices:10.1"multi-point touch screen,capacitive touch screen ,photo could enlarge and shrink,rotation
Store equipment:MINI PCIE SSD/16GB,32GB/64G optional
Other equipment:Could support RJ45 and VGA output
Card reader:SD card,SIM card
USB port:USB2.0*2
Webcam:1.3MP
LAN:10/100 MB
WIFI:Support 802.11B/G/N
Bluetooth:Supported
3G:Optional
Gravity Sensor:360 degree Revolve
Adaptor:AC 110-240V,DC 19V 40W,2.5mm
Specification:
CPU |
Intel ATOM Processor dual CoreN570(1.66GHz) |
Chipset |
Intel NM10 Express chipset |
operation system |
Microsoft® Windows® 7/Linux/Dual OS |
Ram |
1GB 1066MHz DDR3 SDRAM,could enlarge to 2GB |
Store equipment |
MINI PCIE SSD/16GB,32GB/64G optional |
Display screen |
10.1" capacitive multi-point touch screen,1024*600 |
LAN |
10/100 MB |
WIFI |
support 802.11B/G/N |
Bluetooth |
supported |
3G |
optional |
Gravity Sensor |
360 degree Revolve |
Optical Sensor |
according to the environment to adjust the Lcd back light intensity ,which could help saving the power |
Webcam |
1.3MP |
Video ports |
VGA output,not support HDMI outpu |
Audio |
3.5mm/40mw earphone,Stereo speaker |
Card reader |
SD card,SIM card |
USB port |
USB2.0*2 |
Adaptor |
AC 110-240V,DC 19V 40W,2.5m |
|
three cell,2850mAh Lion battery,working time: 3.5H |
Dimension(Length*Width*high) |
Ultra-thin 267mm(length)*173(width)*MIN8mmMAX17mm(high) |
Weight |
900g(including battery) |
Color |
silver |
