Spec.

a(mm)

±

b(mm)

c(mm)

d(mm)

+

e(mm)

±

f(mm)

±

lm(cm)

Ac(cm²)

Wa(cm2)

Ap(cm⁴)

CFCC-6.3

10

0.5

11

33

20

0.5

31

1

53

2

13.1

1.6

3.6

5.8

CFCC-8

11

0.5

13

30

20

0.5

35

1

52

2

13.2

1.8

3.9

7

CFCC-10

11

0.8

13

40

20

0.5

35

1

62

2

15.4

1.8

5.2

9.4

CFCC-16A

11

0.8

13

40

25

0.5

35

1

62

2

15.1

2.3

5.2

12

CFCC-16B

11

0.8

13

50

25

0.5

35

1

72

2

16.9

2.3

6.5

15

CFCC-20

11

0.8

13

50

30

0.5

35

1

72

2

17.5

2.7

6.5

17.6

CFCC-25

13

0.8

15

56

25

0.5

41

1

82

2

19.6

2.7

8.4

22.7

CFCC-32

13

0.8

15

56

30

0.5

41

1

82

2

20

3.2

8.4

26.9

CFCC-40

13

0.8

15

56

35

0.5

41

1

82

2

19.9

3.7

8.4

31.1

CFCC-50

16

0.8

20

70

25

0.5

52

1

102

3

24.9

3.3

14

46.2

CFCC-63

16

1

20

70

30

0.5

52

1

102

3

25.3

3.9

14

54.6

CFCC-80C

16

1

20

70

40

0.5

52

1

102

3

25.4

5.2

14

72.8

CFCC-100

16

1

20

70

45

1

52

1

102

3

25

5.9

14

82.6

CFCC-125

19

1

25

83

35

1

63

1

121

3

30.2

5.4

20.8

112.1

CFCC-160

19

1

25

83

40

1

63

1

121

3

28.5

6.5

20.8

135.2

CFCC-200

19

1

25

83

50

1

63

1

121

3

29.8

7.8

20.8

162.2

CFCC-250

19

1

25

90

60

1

63

1

128

3

31.4

9.3

22.5

209.3

CFCC-320

22

1

35

85

50

1

79

1

129

4

32.5

9

29.8

267.8

CFCC-400

22

1

35

85

65

1

79

1

129

4

33.6

11.7

29.8

348.1

CFCC-500

25

1

40

85

55

1

90

1

135

4

35.6

11.3

34

384.2

CFCC-630

25

1

40

85

70

1

90

1

135

4

35.6

14.3

34

486.2

CFCC-800A

25

1

40

85

85

1.5

90

1

135

4

35.6

17.4

34

591.6

CFCC-800B

30

1

40

85

85

1.5

100

1

155

4

39.3

21

38

798

CFCC-1000

33

1

40

105

85

1.5

106

1

171

5

42.7

23

42

966
