Application:
Power system level by measuring current transformers, precision measuring instruments
(such as the meter) with transformers.
For high accuracy class current transformers like 0.5s , 0.2 , 0.2s and 0.1 class we have a very specialized material commonly known as Nano- crystalline material which will be very useful for your product and you must be using the same .
Performance Comparison of Nanocrystalline Core, Permalloy and Silicon Steel:
Performance Parameters | Nanocrystalline Core | Permalloy Core | Silicon Steel Core |
Saturation Magnetic Induction (Bs) | 1.25 | 0.75 | 1.9 |
Initial Permeability | 4-10×10 4 | 4-8×10 4 | 0.3 |
Maximum Permeability | 60×10 4 | 60×10 4 | 4×10 4 |
Curie Temperature ℃ | 570 | 570 | 740 |
Density(g/cm 3) | 7.3 | 8.75 | 7.65 |
Space Factor(%) | 70-75 | 90 | 95 |
Space Factor(mm) | 0.025-0.042 | 0.15 | 0.3 |
Specification :
![]() |
